Smart BMS LiFePO4 10kwh 48V 200Ah Solar Lithium Ion Server Rack Mounted Battery Pack For Solar System

Smart BMS LiFePO4 10kwh 48V 200Ah Solar Lithium Ion Server Rack Mounted Battery Pack For Solar System

LiFePO4 Server Rack Battery

Smart BMS Server Rack Battery

Solar Lithium ion Server Rack Battery

Place of Origin:

china

Brand Name:

enook

Certification:

IC

Model Number:

51.2V 100A

Contact Us

Request A Quote
Product Details
Estimate Weight:
53kg
Length:
567±2mm
Working Environment:
Charging Temperature:0℃~55℃; Discharge Temperature:-20℃~60℃
Color:
Black
Cycle Life:
≥2500 Cycles 80% Normal Temperature Below 25℃
Nominal Voltage:
51.2V
Internal Resistance(mΩ):
≤20
Width:
510±2mm(excluding Ears)
Payment & Shipping Terms
Minimum Order Quantity
1
Price
900~1900
Product Description

Product Description:

With a Cycle Life of ≥2500 Cycles at 80% Normal Temperature Below 25℃, this battery is built to last. It is a high-quality, long-lasting battery that can be trusted to provide consistent and reliable performance over an extended period of time. This makes it a great choice for businesses and organizations that rely on UPS systems to keep their operations running smoothly.

The estimated weight of this battery is 53kg, with a thickness of 258±2mm and a width of 510±2mm (excluding Ears). This makes it a compact and easy-to-install battery that can be used in a variety of different applications.

This Enook Lithium Iron Phosphate Battery is available in a range of different configurations, including 48V, 51.2V, 100Ah, 200Ah, and 230Ah. It is also capable of delivering up to 5KW or 10KW of power, depending on the configuration that is chosen.

Overall, the Enook Lithium Iron Phosphate Battery is an excellent choice for anyone who needs a reliable and efficient Energy Storage Battery for their UPS system. With its high-quality construction and long-lasting performance, this battery is sure to provide years of reliable service and help keep your operations running smoothly.

Smart BMS LiFePO4 10kwh 48V 200Ah Solar Lithium Ion Server Rack Mounted Battery Pack For Solar System 0
Item
Specification
Conditions


Nominal
Voltage
51.2V


25℃,0.2C
Capacity
200Ah
Module weight
86kg
±1kg
Dimensions(W*D*H), mm
484*222*530
±2mm
Operating parameters
Charging Voltage
52.5V~54.0V

Discharging Voltage
40V

Charging current
Max constant charge: 100A
Recommended 30A
Discharging current
Max constant discharge: 200A



Temperature
Charge range
0℃~45℃

Discharge range
-20℃~55℃

Storage range
-20℃~45℃

BMS
Built-in BMS
Voltage, current, temperature management & cell balance
RS485,CAN communication
Service life
Design life
>10years

Cycle life
>6000 times
Smart BMS LiFePO4 10kwh 48V 200Ah Solar Lithium Ion Server Rack Mounted Battery Pack For Solar System 1

Features:

  • Product Name: Server Rack Battery
  • Internal resistance(mΩ): ≤20
  • Estimate Weight: 53kg
  • Battery Type: LiFePO4
  • Length: 567±2mm
  • Working Environment:
    • Charging Temperature:0℃~55℃
    • Discharge Temperature:-20℃~60℃
  • 48V 51.2V 100Ah 200Ah 230Ah 5KW 10KW compatible
  • Smart BMS System
  • Rack-mounted Server Batteries
Smart BMS LiFePO4 10kwh 48V 200Ah Solar Lithium Ion Server Rack Mounted Battery Pack For Solar System 2

Applications:

enook's Server Rack Battery, model number 51.2V 100A, is a high-quality energy storage battery for UPS, designed and manufactured in China. This product is IC certified, ensuring its safety and reliability for use in critical power applications.

The Server Rack Battery is ideal for use in rack-mounted server batteries, providing backup power and ensuring uninterrupted operation of critical systems during power outages. Its minimum order quantity is 1, and the price range is between 900 and 1900, depending on the quantity ordered.

With a cycle life of ≥2500 cycles at 80% capacity and normal temperature below 25℃, the Server Rack Battery offers a long service life and low maintenance requirements. It has a nominal voltage of 51.2V and is a LiFePO4 battery type, providing high energy density and excellent performance.

The Server Rack Battery has a thickness of 258±2mm and comes in a sleek black color, making it easy to integrate into any server rack system. Its compact design allows for efficient use of space, while its high energy density provides reliable backup power for critical systems.

In summary, enook's Server Rack Battery is a high-quality energy storage battery for UPS, designed for use in rack-mounted server batteries. Its long service life, low maintenance requirements, and high energy density make it a reliable choice for critical power applications.

Smart BMS LiFePO4 10kwh 48V 200Ah Solar Lithium Ion Server Rack Mounted Battery Pack For Solar System 3Smart BMS LiFePO4 10kwh 48V 200Ah Solar Lithium Ion Server Rack Mounted Battery Pack For Solar System 4

Customization:

BMS provides complete management and protection for the battery.
● Voltage warning and protection for module and each single cell.
● Current warning and protection, and the maximum operating current can be customized.
● Temperature warning and protection, 4 sensors for battery pack and 1 sensor for BMS.
● Battery module SOC and SOH calculation, display the accurate battery status.
●Communicate with the SMPS or monitor device, report the battery data.
● Pre-charge/discharge logic, make sure safety charge forlow voltage condition.
● Switch-off mode, sleep mode, and operating mode, different mode for different condition.
Smart BMS LiFePO4 10kwh 48V 200Ah Solar Lithium Ion Server Rack Mounted Battery Pack For Solar System 5Smart BMS LiFePO4 10kwh 48V 200Ah Solar Lithium Ion Server Rack Mounted Battery Pack For Solar System 6

Packing and Shipping:

Product Packaging:

This Server Rack Battery product will be packaged securely in a cardboard box with foam padding to ensure safe delivery. The product will be sealed with tape to prevent any damage or tampering during shipping.

Shipping:

This product will be shipped via a reliable courier service and will be tracked throughout its journey to ensure timely delivery. Shipping costs will be calculated based on the destination and weight of the package.

Smart BMS LiFePO4 10kwh 48V 200Ah Solar Lithium Ion Server Rack Mounted Battery Pack For Solar System 7
